Anemometer WL13

Your reliable partner for accurate and easy wind monitoring.
REQUEST A QUOTATION Click to view Anemometer WL13
This is a product photo of the WL13 anemometer of RDS Weighing & Safety

Info

The WL13 is the ideal solution for easily and accurately monitoring wind conditions. Whether you're evaluating a professional wind site or simply interested in detailed weather information, the WL13 provides everything you need. With wireless range, extensive data storage, and user-friendly features, you can effortlessly track current, average, and maximum wind speed, wind direction, and temperature.

Read on to discover more about the WL13's capabilities.
This is an AI-generated image of a construction site with tower cranes in a windy environment.

Features

  • User-friendly solution for evaluating wind locations
  • Receives, displays, and stores data from up to 3 sensors simultaneously*
  • Stores more than one year of wind history data
  • Displays and stores all important wind and temperature data
  • Wireless range up to 1000 m
  • Up to 1 year battery life
  • Works on battery or external power supply
  • Built-in battery backup real-time clock
  • Backlit LCD display at night
  • WiFi output for sending data to the Navis Livedata web interface*
  • Bluetooth output signal for smartphone via free app*
  • Stores data on SD card with timestamp in real-time*
  • Wind tunnel test report included (if set is ordered)
  • FCC versions available (only for one sensor)

    (*only WL13X/D model)

Functions

  • Current, average, and maximum wind speed
  • Wind direction
  • Temperature
  • History graphs for each installed sensor, 4h and 24h wind speed, 24h wind direction, 24h temperature
  • 30-day history list of daily average/maximum wind speed and maximum/minimum temperature
  • Date and time
  • Maximum and minimum wind speed alarm - acoustic and optical

Compatible sensors

  • Extended range wind speed sensor
  • Extended range wind speed and wind direction sensor

Technical details

Data update 0.5 s; 1 s; 2 s (depends on sensor settings)
Wind speed units m/s, km/h, knots, mph
Wind speed resolution 0,1 m/s
External power suply USB 5V DC (not included)
Battery 3 x 1.5 V, C size Alkaline, LR14 (not included)
Operating temperature -10° ... +50°C
Housing 151 x 80 x 61 mm (PC - Polycarbonate), IP65
SD card (included) Micro SD
Log interval Selectable 1 sec, 5 sec, 10 sec, 1 min, 10 min, 60 min

This product is available for:

  • This is an icon of a building
    Building
    Sites
  • This is an icon of a mobile telescopic crane
    Mobile
    telescopic
    crane
  • This is an icon of a flat top crane
    Flat
    top crane
  • This is an icon of a tower crane
    Tower
    crane
